| General Specifications |
| General Specifications |
| Name/Model |
AIR AMP |
Hardware solution |
SoC: X2000; DAC: ES9020Q; USB chip: XU316; Bluetooth module: AP6256; AMP: TPA3255 |
| Working mode |
USB decoding/Optical decoding/Coaxial decoding/Line IN/Bluetooth receiving/Streaming media receiving/Local playback |
| Color |
Black/silver |
Weight |
About 930g |
| Dimensions |
About 207x188x42mm |
Volume control type |
Knob/remote control |
| Display |
1.1-inch LCD |
Input sensitivity switch |
HIGH/LOW |
| Channel balance |
L20~R20 |
Power control |
Latching push button power switch |
| Supported speaker impedance |
4–8Ω |
Damping factor |
80 |
| Buttons and Ports |
| Knob |
Encoder knob with push button (input switching and menu navigation)*1 + Encoder knob with push button (volume/standby/mute)*1 |
USB |
Type-C USB DAC*2 + USB A*1 |
| DC power input |
DC7909 |
Slide switch |
Input sensitivity switch*1 |
| Single-ended line input |
RCA port |
Optical digital input |
Optical port |
| Coaxial digital input |
RCA port |
Single-ended line output |
Standard 3.5mm port |
| Subwoofer output |
RCA port |
Speaker output |
4mm banana jack (Supports direct bare wire connection) |
| Housing grounding terminal |
4mm banana jack (Supports direct bare wire connection) |
Network |
1000M Ethernet port |
| Special Functions |
| Streaming |
Supports QPlay, AirPlay, Roon Ready, etc. |
Bluetooth reception (5.2) |
SBC/LDAC |
| MQA |
Supports MQA full decoding |
FiiO Link |
Supports FiiO Control |
| Driver-free mode (Switch mode) |
Supported |
Sampling rate support |
USB DAC: Up to 768kHz/32bit; DSD512 (Native) |
| Volume control type |
Knob/remote control |
Local playback: Up to 384 kHz/32-bit; DSD256 |
| Knob indicator light |
Customizable color and brightness; solid-on or RGB breathing |
Streaming playback: Up to 384kHz/32bit; DSD256 |
| Remote control |
IR remote supported (included remote only) |
Coaxial input: Up to 192kHz/24bit, DSD64 |
| Equalizer |
10-band PEQ; 10 built-in EQ presets + 10 custom EQs |
Optical input: Up to 96kHz/24bit |
| Firmware upgrade |
Local upgrade + OTA upgrade |
Wireless network |
2.4G+5G dual-band Wi-Fi |
| Power Supply Parameters |
| Power supply |
DC 48V/≥5A |
|
| Audio Parameters |
| Performance and parameters of speaker output (48V/5A Original power adapter, USB decoding/Coaxial decoding/Optical decoding) |
| Output power |
L+R≥120W+120W (4Ω, THD+N＜1%, 22Vrms) |
Output impedance |
＜0.1Ω (4Ω) |
| L+R≥90W+90W (8Ω, THD+N＜1%, 26.7Vrms) |
Crosstalk |
≥83dB (1kHz@8Ω) |
| THD+N |
＜0.0021% (1kHz/-12dB@8Ω) |
Noise floor |
＜80uV (A-weighted) |
| Dynamic range |
≥110dB (A-weighted) |
SNR |
≥110dB (A-weighted) |
| Frequency response |
20Hz~40kHz: attenuation＜2.4dB |
Peak output voltage |
＞81.3Vp-p |
| 20Hz~20KHz: attenuation＜0.4dB |
|
|
| Performance and parameters of speaker output (48V/5A Original power adapter, LINE IN, HIGH) |
| Output power |
L+R≥120W+120W (4Ω, THD+N＜1%, 22Vrms) |
Output impedance |
＜0.1Ω (4Ω) |
| L+R≥90W+90W (8Ω, THD+N＜1%, 26.7Vrms) |
Crosstalk |
≥78dB (1kHz@8Ω) |
| THD+N |
＜0.002% (1kHz/-15dBV@8Ω) |
Noise floor |
＜80uV (A-weighted) |
| Dynamic range |
≥110dB (A-weighted) |
SNR |
≥110dB (A-weighted) |
| Frequency response |
20Hz~45kHz: attenuation＜2.4dB |
Peak output voltage |
＞81.3Vp-p |
| 20Hz~20KHz: attenuation＜0.3dB |
|
|
| Performance and parameters of speaker output (Powered by 48V/10A, USB decoding/Coaxial decoding/Optical decoding) |
| Output power |
L+R≥190W+190W (4Ω, THD+N＜10%, 27.6Vrms) |
Output impedance |
＜0.1Ω (4Ω) |
| L+R≥100W+100W (8Ω, THD+N＜10%, 28.3Vrms) |
Crosstalk |
≥83dB (1kHz@8Ω) |
| L+R≥155W+155W (4Ω, THD+N＜1%, 24.8Vrms) |
Noise floor |
＜80uV (A-weighted) |
| L+R≥90W+90W (8Ω, THD+N＜1%, 26.7Vrms) |
SNR |
≥110dB (A-weighted) |
| THD+N |
＜0.0021% (1kHz/-12dB@8Ω) |
Dynamic range |
≥110dB (A-weighted) |
| Frequency response |
20Hz~40kHz: attenuation＜2.4dB |
Peak output voltage |
＞81.4Vp-p |
| 20Hz~20KHz: attenuation＜0.4dB |
|
|
| Performance and parameters of speaker output (Powered by 48V/10A, LINE IN, HIGH) |
| Output power |
L+R≥235W+235W (4Ω, THD+N＜10%, 30.8Vrms) |
Output impedance |
＜0.1Ω (4Ω) |
| L+R≥150W+150W (8Ω, THD+N＜10%, 35Vrms) |
Crosstalk |
≥78dB (1kHz@8Ω) |
| L+R≥155W+155W (4Ω, THD+N＜1%, 24.8Vrms) |
Noise floor |
＜80uV (A-weighted) |
| L+R≥90W+90W (8Ω, THD+N＜1%, 26.7Vrms) |
SNR |
≥110dB (A-weighted) |
| THD+N |
＜0.0022% (1kHz/-15dBV@8Ω) |
Dynamic range |
≥110dB (A-weighted) |
| Frequency response |
20Hz~45kHz: attenuation＜2.4dB |
Peak output voltage |
＞81.4Vp-p |
| 20Hz~20KHz: attenuation＜0.3dB |
|
|
| Performance and parameters of single-ended line output (USB decoding/Coaxial decoding/Optical decoding) |
| THD+N |
PCM: 0.0007% (1kHz/-8dB@10kΩ) |
SNR |
≥117dB (A-weighted) |
| Crosstalk |
≥103dB |
Noise floor |
＜3.4uV (A-weighted) |
| Frequency response |
20Hz~80kHz: attenuation＜2.7dB |
Dynamic range |
≥117dB (A-weighted) |
| 20Hz~20KHz: attenuation＜0.2dB |
Line output level |
2.5Vrms (1kHz@10kΩ) |
| Performance and parameters of subwoofer output (USB decoding/Coaxial decoding/Optical decoding) |
| Output level |
4.7Vrms (@20Hz) |
Output impedance |
＜135Ω (10kΩ) |
| Noise floor |
＜3.1uV (A-weighted) |
SNR |
≥123dB (A-weighted) |
| Performance and parameters of subwoofer output (LINE IN) |
| Output level |
5Vrms (@20Hz) |
Output impedance |
＜135Ω (10kΩ) |
| Noise floor |
＜3.1uV (A-weighted) |
SNR |
≥124dB (A-weighted) |
