Five core design | Fully differential true 24Bit R2R resistor arrays DAC Powerful 1150mW+1150mW output | HiFi-grade USB sound card

24 sound presets | HiFi-grade USB/CD Bluetooth transmitter+ turntable Listen while ripping CDs

* Related CDs are not involved in this product.

*Pictures are for reference only. The actual product may vary.

Portable Stereo CD Player DM15 R2R

Truly portable, truly HiFi FIIO portable CD player DM15

After the launch of the DM13, we listened intently to user feedback and diligently refined the product based on their suggestions.

A year later, we present FIIO’s brand-new portable CD player.

•••

The DM15 R2R embodies the latest achievements of FIIO’s research and development and deep expertise in CD technology.

It is not only ‘slimmed down’ compared to the DM13 but also incorporates five core pillars in its design. It brings together the organic analog sound quality of portable CD players and a wealth of modern functionality.

With an advanced configuration, unique functions, simple controls, and high build quality - this is FIIO’s brand-new masterpiece.

Five core design

Comprehensively upgraded

The DM15 R2R represents a breakthrough, combining a smaller footprint with an even stronger feature set. Packed into its portable chassis are five core pillars: the CD Servo, USB DAC, R2R Module, and Bluetooth Module, all managed and coordinated by an MCU (microcontroller unit). Such a thorough “core” evolution elevates the device in every way, surpassing the competition in its product category.

Recreating analog sound

With distinctive characters

Custom fully differential true

24Bit R2R resistor arrays DAC

​​​​​​​

In order to recapture the classic audio character of vintage portable CD players, the DM15 R2R is equipped with a proprietary four-channel, fully differential 24Bit R2R resistor arrays DAC. It is built using a grand total of 192 precision thin- film resistors (48 per channel), carefully selected for their 0.1% accuracy and low temperature drift (30ppm). The result is a nuanced, warm, and organic analog sound.

Custom CD mechanism Reliable disk playback

The DM13’s disc-reading performance has already seen substantial optimization over the past year. The DM15 R2R continues to evolve upon this foundation, with further customization of the CD mechanism. It features a self- rebounding steel ball design for disc alignment, making disc insertion and removal smoother and less likely to scratch the disc.



*The disc-reading capability of the DM15 R2R is comparable to the latest firmware version of the DM13. *Due to the structural limitations of a portable CD mechanism, we cannot guarantee the perfect reading of all CDs. We will continue to optimize disc-reading performance through future firmware upgrades. *Minor skipping when reading certain high-capacity CDs is normal due to variations in mechanisms, manufacturing materials, and recording conditions.

Premium Qualcomm Bluetooth chip Effortless connection Enhanced user experience

Retro meets modern: A dual advancement in both features and experience. Equipped with the Qualcomm QCC3095 Bluetooth chip, the DM15 R2R supports standard and high-resolution Bluetooth transmission protocols, including aptX, aptX Adaptive, aptX HD, and SBC. Bluetooth transmission is supported for both CD input and USB input. A brand-new visual interface makes pairing and connecting Bluetooth devices perfectly clear.



*Differences may exist in Bluetooth protocols among certain brands. Please ensure you set the required Bluetooth codec on the receiving device before connecting.

With 3 BASS modes and 8 built-in EQ presets, you can combine these for up to 24 dynamic sound presets. There is even a specially tuned RETRO sound preset that delivers a rich, analog, and classic sound flavor.



* Since selecting BASS or EQ affects the output level, please adjust your volume as necessary.

Global BASS+EQ

24 sound presets

The all-purpose powerhouse Fully capable

The device combines a portable CD player, HiFi-grade USB DAC, high-resolution USB/CD Bluetooth transmitter, and a USB/CD digital transport all into a single unit - offering far greater versatility and compatibility than comparable portable CD players.

Vintage mechanical controls

The overture to a great listening experience

This brand-new retro design incorporates mechanical buttons, keys, and knobs that one can tangibly interact with, making control simple and easy to learn. Furthermore, the real tactile feedback from every single action allows you to fully experience the beauty of CD listening through sight, touch, and sound.

Slim at an inch Superior in its league

A“powerhouse”among portable CD players

“Portable” CD players are becoming increasingly large, undermining their original purpose of being easy to carry and move around. The DM15 R2R has been further refined and slimmed down in size compared to the DM13. By uniquely integrating high performance and a wealth of features into an extremely compact and portable form factor, it stands out from its competitors.

HiFi-grade USB DAC

Exceptional decoding performance

The highly anticipated USB DAC function is now a reality. While guaranteeing excellent CD sound quality and compatibility, the DM15 R2R also incorporates a HiFi-grade USB DAC. It supports high sampling rates up to 384kHz/32bit and DSD256. Thanks to the R2R DAC, the sound in USB DAC mode is also rendered with distinct musicality.

Supports USB ripping functionality Preserve the melodies that touch your soul

The player supports ripping tracks while listening, allowing you to save your favorite CDs in WAV format onto external storage*. Easily share those unforgettable tunes with friends.

* Only FAT32-formatted external storage devices are supported. * Only CDDA-format music ripping is supported. For system firmware updates or CD ripping, a Type-C flash drive (32GB or smaller) is recommended.

HD TFT display Effortlessly control your music

The player’s retro UI theme blends modern and vintage styles for a pleasing look that is also easy to use. It clearly and intuitively presents information such as battery power, operational mode, EQ settings, sampling rate, Bluetooth connection list, and more, allowing you to easily maintain control over your audio and enhance your musical enjoyment.

Portable and desktop modes

Dual distinct experiences

Patented desktop mode

The battery protection specialist

This mode bypasses the battery for non-portable use, protecting it from being used even during high-power output. This also significantly cuts down on charge-discharge cycles, which significantly helps to prolong the lifespan of the battery.

*If the device power off due to a 0% battery level, charging will automatically commence, even if desktop mode is active, to safeguard the battery’s health.



Patent number: ZL202321946664.8

Infrared remote control included

The included remote makes it easy and convenient to control the device from afar.

High-voltage lithium battery power Freedom on the go

A specially selected 4700mAh, 3.85V pure cobalt high-voltage lithium battery delivers powerful performance to the DM15 R2R. Enjoy about 7 hours* of continuous music playback, easily satisfying your need for extended listening without worrying about the battery running out.



*Data is based on testing from FIIO labs and is for reference only. Actual results may vary due to differences in environment and usage scenario.

Key interface size diagram

① 4.4mm balanced headphone PO

②3.5mm headphone PO

③ BASS selector switch

④Input selector switch

⑤ Output selector switch

⑥ Display screen

⑦ Previous track button

⑧Next track button

⑨ Power button

⑩Volume control knob

⑪ Play/Pause button

⑫ Stop button

⑬ EQ button

⑭ USB REC port

⑮ Desktop mode switch

⑯ Charging indicator light

⑰ PPOWER IN port

⑱ ESP switch

⑲ 3.5mm headphone LO/Coaxial output/Optical output

⑳4.4mm balanced headphone LO

Packing list

① ------------------------------ DM15 R2R Host * 1

② ------------------------------------------- Remote Control * 1

③ ------------- USB-A to Type-C charging data cable * 1

④ ---------------------------- Quick Start Guide * 1

⑤ -3.5mm coaxial patch cord * 1

⑥ ----------------------------------- After-sales maintenance card * 1

ESP (Electronic Shock Protection) Switch

By turning on the ESP functionality, users can enjoy a stable and engaging sound experience whether one is taking the player outside or using it stationary on a desk.

*Enabling the ESP function improves playback stability, but turning the feature on or off does not significantly enhance the disc reading performance.

Transparent window Delivering on both looks and capability

A rich palette of colors: electrophoretic white, silver, black, and red. A true fashion icon that stands out anywhere. The device features a minimalist yet fashionable design, featuring a chassis of all aluminum alloy construction that offers a luxurious texture and tactile feel. Both the transparent lid and the front panel cover are made with tempered glass for increased durability and scratch resistance.
